VP798

Description

FEATURES:

• Dimension:168*180*32mm,weight:450g.
• Electrical spec. of the AC adapter: AC input 100V to 240V, 50/60Hz, DC output 9V/2.0A; power:18W

• 48 Pin ZIF socket with universal pin-drivers.

• Interface with LAPTOP, PC or compatibles through USB port

• Accepts standard file formats: JEDEC, INTEL (Extended) HEX, HOLTEK, EMC(.CDS), INTEL HEX16, Motorola S record

• Manages 16 and 32-bit word split (Set Programming)

• Features Test Vector capability and multiarray fuse map editor

• Test TTL/CMOS logic ICs and Dynamic/Static Random Access Memory devices

• Optimum programming for each individual device

• Automaticly Identifies the manufacturer and type of E(E)PROMs, Auto identifies TTL/CMOS logic IC

• Device insertion and poor-pin-contact check

• Support 1.5v Low voltage devices

• Not need exterior adapter for mostly devices.

• Universal DIP, PLCC, QFP, TSOP, PSOP, SOIC, SSOP, SDIP adapters

• Auto-run mode starts programming automatically upon detection of chip insertion

• Supports WindowsXP/Vista/ Windows 7/8/10

• Supports eight languages,such as
• Chinese(Simplified),Chinese(Traditional),English,Korean,Poland,Italian,Portuguese，Dutch, Turkish and Hungary.

			Power supply
■
	Pack

DEVICE SUPPORT: VIEW
PROM: N/CMOS E(E)PROM, SeriesE(E)PROM, and FLASH Memory
PLD: CPLD, EPLD, GAL,PEEL,PALCE and more
Microcontroller: Atmel, Intel, Microchip, Signetics, Zilog, etc.

IC TEST:
TTL (74 series), CMOS (40/45 series) Logic IC
SRAM (2114, 6116 …) memory device

DEVICE UPDATES:
WEILEI updates software and device algorithm regularly. You can get the latest software free of charge through internet

ORDERING INFORMATION:
rogrammer,cable, manual, software included
15 day moneyback guaranty, one year warranty

WARRANTY & TECHNICAL SUPPORT:
Programmer is warranted to be free of manufacturing or workmanship defects for one year from the date of purchase. Technical support is available by phone Monday through Friday 9:00am to 5:00pm.
